A2-3200
AIDARY
84433990
| Keywords | Jumbo Size Perforating Machine DTF Printer DIY Heat Transfer DTG T Shirt Printing Machine Digital PET Film Printer | |
| Vlotage | 110V/220V | |
| Mainboard | Hoson board | |
| Printer Head | Epson I3200 | |
| Head Number | 2heads or 4heads | |
| Width | A1 size 60cm | |
| Print speed | 10-15/㎡/H | |
Software | include Maintop Software USB | |
| Package | Packed in plywood box | |
| Time | 0-999sec | |
| Advantage | Unique design Portable&Easy to use | |
The DTF printer is developping fast those years. The most important for the machine is mainboard and printer head,the big market for mainboard is : HOSON and senyang, and Epson Printer widely used.And there are 2heads, 4heads, and even 8heads.The more heads more faster printing.
The rest things is the 3main materials: Ink,hot melt powder,and tpu poder,please see below for more details:
About the ink:
The raw resin we use is Mitsui resin
There are two kinds of Mitsui resins in Japan (MUTSUI): 1. The ones produced in Japan are more expensive, 2. The ones produced in Thailand are cheaper, but the quality is not as good as those produced in Japan.
Resin content: more than 20%. If the resin content is not enough, it will affect color fastness, abrasion resistance, friction and tensile strength
The ink will be layered after being put for a long time, with water and color paste on the top and resin on the bottom. So shake up the ink before use
PET film:
There are three kinds of PET film: water-based film, oil-based film, and 3-in-1 film,
The membrane has four layers:
1. Base course (bottom film)
2. Electrostatic layer: prevent the powder from sticking to the side after shaking
3. Ink absorbing layer: prevent ink from flowing everywhere when it is not dry after printing
4. Release layer: for better tearing after high temperature pressing
Hot melt powder:
(1) Melting range (melting point): 115-130 ℃
(2) Ingredients: TPU (polyurethane)
(3) Washing resistance grade (GB 5 is the best): 40 ℃ water washing grade 4, 60 ℃ water washing grade 4, dry cleaning and drying grade 4
(4) Pressing condition: Time: 8-15 seconds Temperature: 120-165 Pressure: 2-4KG
(5) Anti-static, anti-oil, good elasticity, tensile resistance, strong washing fastness, normal drying without cracking (for washing machine with drying function)
Comparison Chart
