Power: | |
---|---|
Voltage: | |
Head Number: | |
Width : | |
Speed: | |
Price: | |
SKU: | |
Availability: | |
Quantity: | |
L1800
AIDARY
84433990
Keywords | AIDARY A3 Dtf Printer L1800 with Shaker And Dryer L1800 Printer DTF Printer | |
Vlotage | 110V/220V | |
Software | RIP software U disk | |
Printer Head | Included | |
Width | A3 | |
Print speed | 0.7-1.5/㎡/H | |
Software | include RIP software U disk | |
Package | Packed in plywood box | |
Time | 0-999sec | |
Advantage | Unique design Portable&Easy to use |
DTF Printer - maintenance and precautions
1、 Printer maintenance
The core component of printer maintenance is the nozzle, and 90% of the maintenance actions are to prolong the service life of the nozzle. The expensive and consumable nozzle naturally becomes a key protection object during our use.
2、 Common main reasons that affect the lifespan of nozzles
1. Nozzle clogged
(1) Ink quality: Poor formulation of resin and raw materials will damage nozzle
(2) Nozzle scratch film during printing process
(3) Not using the machine for a long time
2. Nozzle short circuit and broken
(1) Incorrect or incomplete installation of the cable
(2) Voltage error
(3) Ink/liquid leakage to the connection of cables
3、 Maintenance method of nozzle
1. If the machine is not used for a long time, it is necessary to turn on the machine and clean the nozzle every 1-2 days, and print nozzle test to ensure the integrity of the test image. For more than 3-7 days, distilled or purified water needs to be added to cap station to moisturize the nozzle.
2. After each use of the machine, the nozzle must be reset back to the original station (i.e. the nozzle and ink pad are tightly attached)
3. Before every day printing, it is necessary to turn on the machine and wait for 1-2 minutes. After the white ink circulation and mixing, “Load ink(Manual pump)-head clean-nozzle check” ensure all color+w lines come out well before production.
4. Regularly replace ink cartridges/dampers (3 months) and filters (6 months), depending on the usage of the machine
4、 Precautions
1. 1-Every time before adding white ink to the printer, you need to shake the white ink bottle very hard, to ensure the white ink has no sediment.
2. Before printing, clean the printing platform to prevent any objects from causing eardrums and scratching the nozzle
2. Before printing, the metal clips must be pressed on both sides of the film to prevent the film from scratching the nozzle.
3. Before printing, move the film back and forth to ensure the film is well placed, flat and smooth. to prevent scratching the nozzle.
4. Before printing, you need to do “Load ink(Manual pump)-head clean-nozzle check” to see if the test lines are ok.
5. During printing, it is prohibited to touch the film with any external force (such as hands touching, wind force, etc.) to prevent the film from scratching the nozzle.
6. During printing, if any scraping nozzle problem happen, immediately stop the task and Load ink(Manual pump)-head clean-nozzle check, it problem still there, need to using head cleaner.
7. During printing, it is strictly prohibited for any external force to obstruct the printing action of the nozzle carriage. If necessary, you can press emergency stop to stop printer.
8. After printing, clean the scraper to prevent ink from accumulating, solidifying, and scratching the nozzle
9. After printing, clean the ink pad to prevent ink from accumulating, solidifying, scratching the nozzle, and corroding the ink pad.
10. After printing, the nozzle must be reset (back to ink pad) and moisturized to prevent clogging.
11. It is prohibited to use inferior ink to cause nozzle blockage
11. It is prohibited to plug or unplug the any cable/wire when printer on, it will course short circuit and broken.
12. 13. It is prohibited for any liquid to enter the nozzle wires connection, it will course short circuit and broken.
14. In thunderstorm weather, avoid using machines as much as possible, as there is a risk of broken boards and nozzles
15. If you need to move the machine, prevent collisions that may cause damage to the nozzle or misalignment of the nozzle.
The knowledge on AIDARY A3 Dtf Printer L1800 with Shaker And Dryer L1800 Printer DTF Printer:The main parts on the machine is printer head and mainboard,we are using the hoson mainboard+Epson Printer head I3200, this make up is the most steady.The hoson mainboard is keep the memory on itself ,and others are on the computer that is no steady. Also the Consumables is also important, let me introduce below:
PET film:
There are three kinds of PET film: water-based film, oil-based film, and 3-in-1 film,
The membrane has four layers:
1. Base course (bottom film)
2. Electrostatic layer: prevent the powder from sticking to the side after shaking
3. Ink absorbing layer: prevent ink from flowing everywhere when it is not dry after printing
4. Release layer: for better tearing after high temperature pressing
About the ink:
The raw resin we use is Mitsui resin
There are two kinds of Mitsui resins in Japan (MUTSUI): 1. The ones produced in Japan are more expensive, 2. The ones produced in Thailand are cheaper, but the quality is not as good as those produced in Japan.
Resin content: more than 20%. If the resin content is not enough, it will affect color fastness, abrasion resistance, friction and tensile strength
The ink will be layered after being put for a long time, with water and color paste on the top and resin on the bottom. So shake up the ink before use
Hot melt powder:
(1) Melting range (melting point): 115-130 ℃
(2) Ingredients: TPU (polyurethane)
(3) Washing resistance grade (GB 5 is the best): 40 ℃ water washing grade 4, 60 ℃ water washing grade 4, dry cleaning and drying grade 4
(4) Pressing condition: Time: 8-15 seconds Temperature: 120-165 Pressure: 2-4KG
(5) Anti-static, anti-oil, good elasticity, tensile resistance, strong washing fastness, normal drying without cracking (for washing machine with drying function)
Comparison Chart
Keywords | AIDARY A3 Dtf Printer L1800 with Shaker And Dryer L1800 Printer DTF Printer | |
Vlotage | 110V/220V | |
Software | RIP software U disk | |
Printer Head | Included | |
Width | A3 | |
Print speed | 0.7-1.5/㎡/H | |
Software | include RIP software U disk | |
Package | Packed in plywood box | |
Time | 0-999sec | |
Advantage | Unique design Portable&Easy to use |
DTF Printer - maintenance and precautions
1、 Printer maintenance
The core component of printer maintenance is the nozzle, and 90% of the maintenance actions are to prolong the service life of the nozzle. The expensive and consumable nozzle naturally becomes a key protection object during our use.
2、 Common main reasons that affect the lifespan of nozzles
1. Nozzle clogged
(1) Ink quality: Poor formulation of resin and raw materials will damage nozzle
(2) Nozzle scratch film during printing process
(3) Not using the machine for a long time
2. Nozzle short circuit and broken
(1) Incorrect or incomplete installation of the cable
(2) Voltage error
(3) Ink/liquid leakage to the connection of cables
3、 Maintenance method of nozzle
1. If the machine is not used for a long time, it is necessary to turn on the machine and clean the nozzle every 1-2 days, and print nozzle test to ensure the integrity of the test image. For more than 3-7 days, distilled or purified water needs to be added to cap station to moisturize the nozzle.
2. After each use of the machine, the nozzle must be reset back to the original station (i.e. the nozzle and ink pad are tightly attached)
3. Before every day printing, it is necessary to turn on the machine and wait for 1-2 minutes. After the white ink circulation and mixing, “Load ink(Manual pump)-head clean-nozzle check” ensure all color+w lines come out well before production.
4. Regularly replace ink cartridges/dampers (3 months) and filters (6 months), depending on the usage of the machine
4、 Precautions
1. 1-Every time before adding white ink to the printer, you need to shake the white ink bottle very hard, to ensure the white ink has no sediment.
2. Before printing, clean the printing platform to prevent any objects from causing eardrums and scratching the nozzle
2. Before printing, the metal clips must be pressed on both sides of the film to prevent the film from scratching the nozzle.
3. Before printing, move the film back and forth to ensure the film is well placed, flat and smooth. to prevent scratching the nozzle.
4. Before printing, you need to do “Load ink(Manual pump)-head clean-nozzle check” to see if the test lines are ok.
5. During printing, it is prohibited to touch the film with any external force (such as hands touching, wind force, etc.) to prevent the film from scratching the nozzle.
6. During printing, if any scraping nozzle problem happen, immediately stop the task and Load ink(Manual pump)-head clean-nozzle check, it problem still there, need to using head cleaner.
7. During printing, it is strictly prohibited for any external force to obstruct the printing action of the nozzle carriage. If necessary, you can press emergency stop to stop printer.
8. After printing, clean the scraper to prevent ink from accumulating, solidifying, and scratching the nozzle
9. After printing, clean the ink pad to prevent ink from accumulating, solidifying, scratching the nozzle, and corroding the ink pad.
10. After printing, the nozzle must be reset (back to ink pad) and moisturized to prevent clogging.
11. It is prohibited to use inferior ink to cause nozzle blockage
11. It is prohibited to plug or unplug the any cable/wire when printer on, it will course short circuit and broken.
12. 13. It is prohibited for any liquid to enter the nozzle wires connection, it will course short circuit and broken.
14. In thunderstorm weather, avoid using machines as much as possible, as there is a risk of broken boards and nozzles
15. If you need to move the machine, prevent collisions that may cause damage to the nozzle or misalignment of the nozzle.
The knowledge on AIDARY A3 Dtf Printer L1800 with Shaker And Dryer L1800 Printer DTF Printer:The main parts on the machine is printer head and mainboard,we are using the hoson mainboard+Epson Printer head I3200, this make up is the most steady.The hoson mainboard is keep the memory on itself ,and others are on the computer that is no steady. Also the Consumables is also important, let me introduce below:
PET film:
There are three kinds of PET film: water-based film, oil-based film, and 3-in-1 film,
The membrane has four layers:
1. Base course (bottom film)
2. Electrostatic layer: prevent the powder from sticking to the side after shaking
3. Ink absorbing layer: prevent ink from flowing everywhere when it is not dry after printing
4. Release layer: for better tearing after high temperature pressing
About the ink:
The raw resin we use is Mitsui resin
There are two kinds of Mitsui resins in Japan (MUTSUI): 1. The ones produced in Japan are more expensive, 2. The ones produced in Thailand are cheaper, but the quality is not as good as those produced in Japan.
Resin content: more than 20%. If the resin content is not enough, it will affect color fastness, abrasion resistance, friction and tensile strength
The ink will be layered after being put for a long time, with water and color paste on the top and resin on the bottom. So shake up the ink before use
Hot melt powder:
(1) Melting range (melting point): 115-130 ℃
(2) Ingredients: TPU (polyurethane)
(3) Washing resistance grade (GB 5 is the best): 40 ℃ water washing grade 4, 60 ℃ water washing grade 4, dry cleaning and drying grade 4
(4) Pressing condition: Time: 8-15 seconds Temperature: 120-165 Pressure: 2-4KG
(5) Anti-static, anti-oil, good elasticity, tensile resistance, strong washing fastness, normal drying without cracking (for washing machine with drying function)
Comparison Chart
1.Manufacturer
Place the order directly to factory ,no have intermediate cost
2.Fast delivery
we can send out the order within 3-5working days after payment confirm,big order after getting bank receipt.
3.Strict QC controlle
quality is the life of our company,we check all the goods before sending,
4.Stable Supply
We have sufficient stock for sublimation materials
5.Professional after sales service
We will give you very professional service, our sales team will service you in good attitude, no-matter you are a wholes sales or end client.
6.More than 10years experience
we have in heat press and sublimation materials for more than 10years we have many experience in this field ,if you have any questions or problem in this field we can help you to solved.
7.OEM/ODM acceptable
We can do OEM/ODM for you,no have MOQ required.
About payment
We accet TT(to our company bank account not person account),Western Union,Paypal,Escrow
We send the goods to over sea by sea ,by air ,or by Express
-By sea: need at least 20boxes of order,just to seaport
-By express: 0-45kgs that is best choose to send the goods by express and it is door to door delivery.
-By air:45kgs to 100kgs, this way is just to the air port not to your door.
Drop shipment also acceptable, we wont not show our information if we do drop shipment.
Firstly: send us the products list which you want to order(more details more better) also give us CONSIGNEE INFO
Sencondly: We will send you PROFORMA INVOICE with freight and bank details
Thirdly: when you confirm the invoice, pls do the payment and send us the bank receipt and we will start to prepare the order for you
Fourly, when the goods ready we will send out ,after sending out we will giveyou tracking number or BL(for sea shipment)
